STAGE 2
Stage 2 has a total area of 15,532 SF. It features adjacent support spaces and is directly accessible to the basecamp and parking areas.
Glendale’s stages feature state-of-the-art soundproofing, integrated smart grid analog style control systems and ample power distribution. The stage is fully equipped to support single cam and multi cam television productions, feature films and digital production workflows (XR and VR capable) as well as commercial and marketing campaigns.
See specifications below for details.
- Area: 15,532 SF
- Height: 36.5'
- Dimension: 135'6" x 127' x 102'5" x 128’6”
- Cyc: 48' x 35' x 20'
Specifications
Expand All +Structure
- 6″ thick concrete slab-on-grade for a stage floor max load of 500 lbs/sf
- Open-web steel joist roof, with steel joists spaced 8′ on-center
- Truss supports 12.5 lbs/sf of suspended production loads
- Clear span
- 24″ sound mitigated rathole
Sound
- Acoustically designed with 12″-thick insulated concrete walls; InsulQuilt lined walls, black
- Wall assembly achieves STC Rating of 65+
- Designed to minimum noise criteria rating of NC-25
- 20′ x 20′ sliding elephant doors, STC-53 rated (x2)
- Personnel access via STC rated hollow metal doors with sound locks
Power
Stage 1 (in a single stage configuration) has a 4000A 120/208V, 3 phase 4 wire panel providing service via:
- Cam Lock #1 | 600A
- Cam Lock #2 | 400A
- Cam Lock #3 | 200A
- +800 amps of distributed power
Air/HVAC
- 150 ton/SF provided via 11 rooftop units with 10,000 CFM supply fans
- 4 additional theatrical exhaust fans sit atop the stage
- Vibration isolators and in-line silencers provide near silent operations
- Flex-duct connections
Security
- MPAA compliant
- 12 MP dome cameras: 360°, vandal/weather resistant with full exterior coverage
- License plate and facial recognition capable
- 30 days local storage; cloud storage for tagged events
- 6′ high perimeter fence & walls
CYC
- 48’ wide × 35’ deep × 20’ high, two-wall curved cyc wall.
